06 Jun 2016 19:37 #50056 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
@ledvinap, can you put SPI traces to some file sharing and post a link here?

Please Log in or Create an account to join the conversation.

More
06 Jun 2016 20:38 #50061 by anasm2010
Replied by anasm2010 on topic Radiolink AT9 as a platform for Deviation?
Thank you
Yes there is only 1 dfu file on the Nightly build

Please Log in or Create an account to join the conversation.

More
07 Jun 2016 14:08 - 07 Jun 2016 14:11 #50089 by ledvinap
Replied by ledvinap on topic Radiolink AT9 as a platform for Deviation?
Dumps are attached, only exported SPI-decoded data from saleae

here is (quick-and-dirty) script to decode them: gist.github.com/ledvinap/d603d929e9444340f3b9033e30cd547a

and all files I currently have, zipped: drive.google.com/file/d/0B9HM4UOKDQBLV2F...cmM/view?usp=sharing
Attachments:
Last edit: 07 Jun 2016 14:11 by ledvinap.

Please Log in or Create an account to join the conversation.

More
07 Jun 2016 16:09 #50103 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
How about timing? That's why I prefer original undecoded traces - you can look at them with your own eyes, study timing, decode to your wishes - sometimes people use non-standard settings in SPI, for instance.

Please Log in or Create an account to join the conversation.

More
08 Jun 2016 15:17 #50177 by ledvinap
Replied by ledvinap on topic Radiolink AT9 as a platform for Deviation?
@victzh : Sorry, I did not save any trace. I'll post some when I open AT9 next time..
SPI was pretty standard (default saleae decoder settings). CC2533 SPI slave isn't too configurable ...

Please Log in or Create an account to join the conversation.

More
08 Jun 2016 15:47 #50178 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
No problem. Next 3 weeks I will not be able to do anything with it, but I'll need your traces for comparison - the more TXs we trace the easier to find commonality and difference.

Please Log in or Create an account to join the conversation.

More
08 Jun 2016 18:32 #50193 by PhracturedBlue
Replied by PhracturedBlue on topic Radiolink AT9 as a platform for Deviation?
I did add the filesystem dfu to the nightlies. they should be there now.

Please Log in or Create an account to join the conversation.

More
16 Jun 2016 12:19 #50692 by ledvinap
Replied by ledvinap on topic Radiolink AT9 as a platform for Deviation?
Here are Saleae-saved data : drive.google.com/file/d/0B9HM4UOKDQBLX0p...T1U/view?usp=sharing
Just power on + some stick movements. Use SPI exports for protocol data

Please Log in or Create an account to join the conversation.

More
01 Jul 2016 16:53 - 01 Jul 2016 16:56 #51243 by HappyHarry
Replied by HappyHarry on topic Radiolink AT9 as a platform for Deviation?
some data here for the new at9s >> m.banggood.com/RadioLink-AT9S-2_4GHz-10C...eiver-p-1062334.html don't know what has changed tbh
Last edit: 01 Jul 2016 16:56 by HappyHarry.

Please Log in or Create an account to join the conversation.

More
01 Jul 2016 22:23 #51249 by aMax
Replied by aMax on topic Radiolink AT9 as a platform for Deviation?
New protocol?
AT9 = DSSS system
AT9S = DSSS & FHSS
....like Spektrum DSM2 and DSMX..
Devo7e, TaranisQ X7, R9M , 4in1 MM, Futaba FC18plusV3.2 & DFT/FLD-02

Please Log in or Create an account to join the conversation.

More
01 Jul 2016 22:51 #51250 by anasm2010
Replied by anasm2010 on topic Radiolink AT9 as a platform for Deviation?
Looking at the manual they use the same spread spectrum (DSSS& FHSS). The only difference I see is the color and the consumption power... I don't know if the internal are the same? Maybe yes.
at9s -> radiolink.com.cn/doce/product-detail-119.html
at9 - > radiolink.com.cn/doce/product-detail-89.html

Please Log in or Create an account to join the conversation.

More
06 Jul 2016 14:00 #51359 by vlad_vy
Replied by vlad_vy on topic Radiolink AT9 as a platform for Deviation?
AT9S probably will have 512K Flash memory.

Attachments:

Please Log in or Create an account to join the conversation.

More
06 Jul 2016 14:29 #51360 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
AT9, without S, already has an MCU with 512KB of flash.

Please Log in or Create an account to join the conversation.

More
06 Jul 2016 15:18 #51362 by bianchifan
Replied by bianchifan on topic Radiolink AT9 as a platform for Deviation?

anasm2010 wrote: ..The only difference I see is the color and the consumption power..

AT9S is a 10! channel TX, much more configurable than the AT10.

Please Log in or Create an account to join the conversation.

More
06 Jul 2016 18:37 #51366 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
And it is almost immaterial for the purpose of using it as a new platform for Deviation. For standard Deviation use pattern we're replacing the radio part with our own radio module and it becomes just another (well-specced - powerful processor, large number of switches and pots) Deviated TX.

Another use - Deviation on unmodded AT9 supporting native Radiolink protocol - is not there yet. For this use differences in radios may be in radio module, not in the TX itself.

Please Log in or Create an account to join the conversation.

More
07 Jul 2016 10:26 #51392 by anasm2010
Replied by anasm2010 on topic Radiolink AT9 as a platform for Deviation?
The AT9 have also 10 channel :)

Please Log in or Create an account to join the conversation.

More
07 Jul 2016 10:28 #51393 by anasm2010
Replied by anasm2010 on topic Radiolink AT9 as a platform for Deviation?
And the R9DS work same with AT9 and the AT9s

Please Log in or Create an account to join the conversation.

More
07 Jul 2016 11:16 #51396 by vlad_vy
Replied by vlad_vy on topic Radiolink AT9 as a platform for Deviation?

victzh wrote: AT9, without S, already has an MCU with 512KB of flash.


Uppss, I thinking about main board flash memory.

Please Log in or Create an account to join the conversation.

More
07 Jul 2016 14:35 #51406 by victzh
Replied by victzh on topic Radiolink AT9 as a platform for Deviation?
@anasm2010 - and these 10 channels are almost totally irrelevant - Deviation currently does not support native Radiolink protocol, but replaces the radio module altogether with one compatible with hundreds of models supported by Deviation.

What's important is original AT9's price drop - it can be found on Amazon for less than $100.

Please Log in or Create an account to join the conversation.

More
07 Jul 2016 14:42 #51407 by anasm2010
Replied by anasm2010 on topic Radiolink AT9 as a platform for Deviation?
@victzh - Yes I know, just wanted to answear to @bianchifan...
Do you know when the deviation will be operational?
What upgrade for memory need to be done and with witch chip?
Is this the RF module that will replace the existent?
-http://m.banggood.com/2_4G-CC2500-A7105-Flysky-Frsky-Devo-DSM2-Multiprotocol-TX-Module-With-Antenna-p-1048377.html
-http://www.banggood.com/DIY-2_4G-CC2500-NRF24L01-A7105-CYRF6936-Multi-RF-4-IN-1-Wireless-Module-p-1046308.html
Thank you
